Kulkoni, Inc.
CM
WARNING: NEVER EXCEED WORKING LOAD LIMIT
GALVANIZED SCREW PIN ANCHOR SHACKLES
GALVANIZED BOLT TYPE ANCHOR SHACKLES
Size
(A)
Working Load
Limit in Tons
Pin Diam.
In Inches
(B)
Approx. Weight
Each in Pounds
Dimensions in Inches
C
D
E
F
3/16"
1/3
1/4
0.05
0.88
0.38
0.56
0.63
1/4"
3/4
5/16
0.13
1.06
0.47
0.66
0.75
5/16"
1
3/8
0.21
1.25
0.53
0.81
0.84
3/8"
1.1/2
7/16
0.33
1.44
0.63
0.97
1.00
7/16"
2
1/2
0.47
1.69
0.75
1.06
1.13
1/2"
3
5/8
0.76
1.88
0.81
1.31
1.25
5/8"
4.1/2
3/4
1.44
2.44
1.06
1.56
1.69
3/4"
6.1/2
7/8
2.30
2.88
1.19
1.88
1.94
7/8"
8.1/2
1
3.50
3.38
1.44
2.13
2.19
1"
10
1.1/8
5.00
3.81
1.69
2.38
2.63
1.1/8"
12
1.1/4
7.00
4.25
1.75
2.63
2.88
1.1/4"
14
1.3/8
9.50
3.97
2.00
2.91
3.13
1.3/8"
17
1.1/2
13.00
5.31
2.13
3.25
3.50
1.1/2"
20
1.5/8
16.50
5.69
2.31
3.50
3.75
1.3/4"
30
2
29.00
7.06
2.88
4.25
4.88
2" *
35
2.1/4
43.00
7.75
3.31
4.88
5.44
2.1/2" *
55
2.3/4
90.00
10.50
4.13
6.25
6.75
3" *
85
3.1/4
138.00
13.00
5.00
6.75
7.38
* NOTE: Working Load limits equal to industry standard not to CM higher ratings.
